CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision

CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision
CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision

Gambar besar :  CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision

Detail produk:
Tempat asal: Jiangsu, Cina
Nama merek: Suma
Nomor model: MI500 MG500
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 2
Harga: $100
Kontak

CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision

Deskripsi
Peringkat presisi: P0 Tipe Segel: Tertutup
Jenis: CAM Bor Dia.: 31.5mm
Keyway: 7mm x3mm Berat: 5.0KG
Toleransi Poros: H6 atau H7 (standar JIS) Standar kunci: Jis B1301-1959
Suhu maksimal: 70°C Pelumasan: Oli tidak disegel (pasokan sebelum digunakan)
Arah Pemasangan: Vertikal (konsultasikan untuk spesifik) Beban dorong: Tidak didukung (gunakan perangkat lain)
Jenis Kunci: Kunci paralel saja Ventilasi tekanan: Diperlukan untuk seri MG
Kecepatan overrunning: Tentukan untuk MG750 dan di atas
Menyoroti:

CAM Clutch Bearing 31.5mm bore

,

Sealed P0 precision clutch bearing

,

One way clutch bearing with warranty

Cam Clutch MI500 MG500 One Way Clutch Bearing
CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 0
Product Features
  • MG Series Cam Clutch is designed for inner race overrunning applications
  • MI Series Cam Clutch is optimized for indexing applications
  • Easy attachment to pulleys, gears, or sprockets using high-tension bolts
  • Compatible with JIS standard H6 or H7 tolerance bores
  • Includes pressure ventilation hole for MG Series models
Installation Guidelines
  • Use only parallel keys (tapered keys are prohibited)
  • For shock loads or full torque capacity, use hardened key and shaft
  • Apply mounting pressure only to the inner race, never the outer race
  • Thrust load must be handled by separate devices, not the clutch
  • For MG Series models MG750 and above, specify overrunning speed when ordering
  • Consult manufacturer for vertical mounting applications
Operating Conditions
  • Monitor temperature - longevity decreases above 70°C outer race temperature
  • For continuous overrunning at medium/high speeds, consider oil bath or forced lubrication
  • No oil is sealed during shipment - add appropriate lubrication before use
Model Specifications
CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 1 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 2
Product Images
CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 3 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 4 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 5 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 6 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 7 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 8
Packaging
CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 9 CAM Clutch Bearing MI500 MG500 31.5mm Bore Sealed P0 Precision 10

Label:

Sprag Clutch One Way Bearing,

Sprag One Way Clutch Bearing,

Freewheel One Way Sprag Clutch
